| Place of Origin: | GUANGZHOU |
|---|---|
| Brand Name: | Wakestone |
| Model Number: | OT2050（OT2000） |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | standard packing |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 Piece/Pieces per Week |
| Impact Frequebcy: | 100-200 Bpm | Suitable Excavator(ton): | 55-70ton |
|---|---|---|---|
| Chisel Diameter: | 205mm | Name: | Hydraulic Crushing Hammer Machine |
| Weight: | 6420 KG | Hydraulic Flow Range: | 260-300 L/min |
| Operating Pressure: | 290-3100 Bar | Back Head Pressure: | 30-35kg/cm² |
| Highlight: | OT2050 Excavator Mounted Jack hammer,70 Ton Excavator Rock Hammer,OT2000 Excavator Mounted Jack hammer |
||
What Are the Components of A Hydraulic Breaker?
Your excavator’s hydraulic breaker has several components that work together systematically to deconstruct stone elements. Check them out:
Side Rods,Nitrogen Chamber,Auto-grease System,Piston Mass and Supporting Area,Control Valve,Seal kit,Retainer Pins,Hardened Chisel and Stop Pin
All these are the basic components of any excavator hydraulic breaker. Different brands may have additional components. It is thus advisable to keep your hydraulic breaker’s operations and service manuals close to you.
All hydraulic breakers come with an enclosure that protects all their components from physical damages.
| Ltem | Units | 0T 2050 | 0T 2000 | |
| Job weight | Side type | kg | 6420 | 6015 |
| Top type | kg | / | / | |
| Box type | kg | / | / | |
| Operating pressure | bar | 290-3100 | 290-310 | |
| Required oil flow | l/min | 260-300 | 260-310 | |
| Impact Rate | bpm | 100-200 | 100-200 | |
| Hoses Diameter | inch | 1 1/2” | 1 1/2” | |
| Back Head Pressure | kg/cm² | 30-35 | 30-35 | |
| Tool Diameter | mm | 205 | 200 | |
| Suitable Excavator | Ton | 55-70 | 55-70 | |
How Should I Grease My Excavator Hydraulic Breaker?
Greasing your excavator hydraulic breaker is an important task as it helps maintain the device as well as ensure that it lasts for long while serving you. These hydraulic breakers are designed to withstand harsh and abusive environmental conditions.
You’ll need to use the correct type and amount of grease to make the greasing process a success. You’ll need to grease your excavator hydraulic breaker’s chisel and bushings. If the excavator hydraulic breaker has insufficient grease, it will overheat.
When the hydraulic breaker heats up too much, it seizes and in most extreme cases, this overheating ends up damaging other components.
You’ll therefore need to contact your local mechanic who’ll recommend the best brand and/or type of grease to use, depending on your environmental condition.
