| Place of Origin: | GUANGZHOU |
|---|---|
| Brand Name: | Wakestone |
| Model Number: | YSB140 |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | standard packing |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 Piece/Pieces per Week |
| Impact Frequebcy: | 360-460bpm | Suitable Excavator(ton): | 18-26 Ton |
|---|---|---|---|
| Chisel Diameter: | 140mm | Name: | Excavator Rock Breaker |
| Weight: | 920KG | Hydraulic Flow Range: | 120-180 |
| Highlight: | Rock Breaker Hydraulic Hammer,YSB140 Hydraulic Hammer,460bpm Hydraulic Hammer |
||
Product model and relevant data
| Specname | Unit | YSBT135 | YSB135A | YSB140 | YSB140A | YSB150 | YSB150A |
| Body weight | kg | 850 | 846 | 920 | 956 | 985 | 1092 |
| Total weight | kg | 1658/1825/1898 | 1688/1868/1918 | 1767/2052/2004 | 1805/2090/2042 | 1692 | 2218/2380/2457 |
| size | mm | 2423*5008*1202 | 2427*500*1202 | 2480*590*1355 | 2480*590*1355 | 2456*5959*1288 | 2640*590*1343 |
| 2900*560*710 | 2656*560*710 | 2866*560*710 | 2866*560*710 | 2879*600*760 | |||
| 2847*560*710 | 2646*560*710 | 2793*560*710 | 2793*560*710 | 3002*640*760 | |||
| Operating pressure | Kg/cm² | 160-180 | 160-180 | 160-180 | 160-180 | 180-200 | 180-200 |
| Hydraulic flow range | L/min | 130-150 | 145-180 | 120-180 | 120-180 | 130-180 | 150-190 |
| Diameter of house | inch | 1 | 1 | 1 | 1 | 1 | 1 |
| Diameter of tool | mm | 135 | 135 | 140 | 140 | 150 | 155 |
| Impact frequebcy | bpm | 400-800 | 700-1200 | 360-460 | 350-500 | 350-500 | 350-700 |
| Suitable carrier | ton | 18-26 | 18-26 | 18-26 | 18-26 | 20-26 | 27-35 |
Your excavator’s hydraulic breaker has several components that work together systematically to deconstruct stone elements. Check them out:
Side Rods– They are uniquely designed for mounted hammer applications. These side rods can be easily maintained as their maintenance tools are mostly found in local shops.
Nitrogen Chamber– its main purpose is to absorb the piston recoil and reuse the absorption energy to increase the output strength for a greater blow.
Auto-grease System– This is an optional feature that auto-greases the hydraulic breaker, just as its name suggests.
Piston Mass and Supporting Area– the main purpose of this component is to ensure that there is positive alignment in the entire system. It, therefore, makes the whole system effective and efficient.
Control Valve– the control valve’s primary purpose is to reduce hydraulic pulsations as it minimizes oil flow interruptions.
Seal kit– Your excavator hydraulic breaker has rubber seals in it that prevent hydraulic fluid leakage as well as helping generate the optimal hydraulic pressure.
Retainer Pins– They also aid in providing positive tool alignment as well as a quick replacement.
Hardened Chisel and Stop Pin– the chisel is one of the main components of a hydraulic breaker, as it gets into direct contact with the ground/stone material.
All these are the basic components of any excavator hydraulic breaker. Different brands may have additional components. It is thus advisable to keep your hydraulic breaker’s operations and service manuals close to you.
All hydraulic breakers come with an enclosure that protects all their components from physical damages.
