| Place of Origin: | CHINA |
|---|---|
| Brand Name: | Wakestone |
| Certification: | OEM |
| Model Number: | 705-14-41040 705-12-44010 |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotiated |
| Packaging Details: | Standard shipping package |
| Delivery Time: | About 15 Days After Receiving The Deposit(Based On The Quantity) |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 500 pieces per month |
| Material: | High Strength Steel | Product Name: | High Frequency Excavator Breaker Hammer |
|---|---|---|---|
| Working Pressure:: | 90-120kg/cm2 | Application: | Pile Driving |
| Name: | Excavator Breaker Hammer | Drilling Depth: | 1700mm |
| Highlight: | 13.5cm Hydraulic Breaker Hammer,Pile Driving Hydraulic Breaker Hammer,Skid Steer Hydraulic Breaker Hammer |
||
13.5cm Crawler Excavator Hydraulic Breaker For SB20 3 Ton
Please click here to tell us which type you need.
1) Easy maintenance, only need a small amount of wearing parts inventory.
2) High quality.Our quality and strike strength can be compared with European, Japanese and Korean hydraulic breakers.
3) Low price.The price is 30%~60% of the European, Japanese and Korean hydraulic breakers.
4) We produce various types of Korea and Japan hydraulic breakers, which are suitable for all kinds of excavators.
5) Good raw material with strictly heat treatment processor.
6)Strict material selection, processing and assembly process, 100% quality inspection and strike test before delivery
7) With ISO & CE certification, our HMB hydraulic breakers have been accepted by more than 50 countries in the world.
|
model
|
unit
|
DEHN1400
|
DEHN1550
|
DEHN1650
|
DEHN1750
|
|
operation weight(side/top/box)
|
kg
|
1774/2059/1866
|
2577/2745/2968
|
2751/3156/2916
|
3905/4057/3902
|
|
length(side/top/box)
|
mm
|
2480/2866/2793
|
2776/3102/3075
|
2820/3285/3337
|
3184/3812/3723
|
|
working flow rate
|
1iter/min
|
120-180
|
180-240
|
200-260
|
200-260
|
|
oil relief pressure
|
kg/cm²
|
210
|
230
|
240
|
240
|
|
working pressure
|
kg/cm²
|
160-185
|
170-200
|
160-180
|
180-200
|
|
impact rate
|
bpm
|
350-500
|
300-450
|
250-400
|
200-350
|
|
chisel diameter
|
mm
|
¢140
|
¢1550
|
¢162
|
¢1750
|
|
oil pipe nominaldiameter
|
inch
|
1
|
1
|
5/4
|
5/4
|
|
back head pressure
|
kg/cm²
|
16±0.5
|
16±0.5
|
16±0.5
|
16±0.5
|
|
Accumulator pressure
|
kg/cm²
|
60
|
60
|
60
|
60
|
|
Applicable Excavator weight
|
ton
|
18-26
|
27-36
|
30-40
|
35-40
|
|
Applicable Bucket
|
m³
|
0.9-1.2
|
1.0-1.4
|
1.6-2.2
|
1.6-2.2
|
|
Value Position
|
|
internal
|
internal
|
internal
|
internal
|
Side Type Breaker
1.Reducing total-length
2.More easier to handle
the breaking objects
3. low maintenance.
Top Type Breaker
1.Easy-operating to achieve excavation work
2.Without side weight, reducing the rate of chisel breakage
3.longer total-length and heavier total-weight
Silence Box Type Breaker
1.Low noise level
2.Full-closed bracket protects
main body from damage.
